Universal Trash Can Dumpers

model: TCD-U-48-DC



Featured Ergonomic Solutions


Linear Actuated Adjustable-Height Work Bench
Linear Actuated Elevating Cart (partially stainless steel)
Ball Transfer Strips & Single Ball Transfers
Battery Transfer Platforms
Stackers with Lithium Ion Battery
Low Profile Electric Lift Tables
Roller & Ball Conveyors
Multi-Purpose Tote Dumpers
Premium Scissor Lift Carts
model chart

Product Family Overview

Print Friendly
Universal Trash Can Dumpers
SERIES: TCD-U

This innovative product allows one person to easily load, maneuver, and dump heavy trash cans of various sizes. The large squared chute and hold-down fingers allow this product to dump and retain most trash cans. Works with trash cans measuring 17-1/2" to 34-3/4" wide, 20-1/2" to 35-7/8" long, and 27" to 50" high. Multiple operations available; 115V AC, and 12V DC power with one (1) battery and an on-board charger, battery charge indicator gauge are standard. Units roll smoothly on (2) two swivel and (2) two rigid 8" x 2" glass filled nylon casters. Two (2) adjustable floor locks are also included. Ships fully assembled.

  • Simple design easily dumps contents out of trash can
  • Caster design makes portability convenient
  • Dump heights allow user to dump trash into tall dumpsters
  • Heavy duty steel construction is built to last

This innovative product allows one person to easily load, maneuver, and dump heavy trash cans of various sizes. The large squared chute and hold-down fingers allow this product to dump and retain most trash cans. Works with trash cans measuring 17-1/2" to 34-3/4" wide, 20-1/2" to 35-7/8" long, and 27" to 50" high. Multiple operations available; 115V AC, and 12V DC power with one (1) battery and an on-board charger, battery charge indicator gauge are standard. Units roll smoothly on (2) two swivel and (2) two rigid 8" x 2" glass filled nylon casters. Two (2) adjustable floor locks are also included. Ships fully assembled.

  • Simple design easily dumps contents out of trash can
  • Caster design makes portability convenient
  • Dump heights allow user to dump trash into tall dumpsters
  • Heavy duty steel construction is built to last

Other Dumpers

 Multi-Purpose Tote Dumpers Electric Hydraulic Trash Can Dumpers Trash Cans Trash Can Carts

Additional Models In This Family
view entire Image Gallery

TCD-U-60-AC

model TCD-U-60-AC

TCD-U-60-DC

model TCD-U-60-DC

model chart
How To Purchase

Model Specific Details

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
The Search Box below is within the Model Chart for this Product Family (on this current page). Not an entire site search.
Model # Description Attributes Net Wt.
(lbs)
TCD-U-48-AC
TCD-U-48-AC1 Year Limited WarrantySteel Universal AC Powered Trash Can Dumper 48 In. Maximum Dump Height Blue / YellowUniform Capacity (lb.): 400
Maximum Dump Height (in.): 48		888
TCD-U-48-DC TCD-U-48-DC1 Year Limited WarrantySteel Universal DC Powered Trash Can Dumper 48 In. Maximum Dump Height Blue / YellowUniform Capacity (lb.): 400
Maximum Dump Height (in.): 48-9/16		908
TCD-U-60-AC
TCD-U-60-AC1 Year Limited WarrantySteel Universal AC Powered Trash Can Dumper 60 In. Maximum Dump Height Blue / YellowUniform Capacity (lb.): 400
Maximum Dump Height (in.): 59-15/16		864
TCD-U-60-DC TCD-U-60-DC1 Year Limited WarrantySteel Universal DC Powered Trash Can Dumper 60 In. Maximum Dump Height Blue / YellowUniform Capacity (lb.): 400
Maximum Dump Height (in.): 59-13/16		942
TCD-U-72-AC
TCD-U-72-AC1 Year Limited WarrantySteel Universal AC Powered Trash Can Dumper 72 In. Maximum Dump Height Blue / YellowUniform Capacity (lb.): 400
Maximum Dump Height (in.): 71-15/16		991
TCD-U-72-DC TCD-U-72-DC1 Year Limited WarrantySteel Universal DC Powered Trash Can Dumper 72 In. Maximum Dump Height Blue / YellowUniform Capacity (lb.): 400
Maximum Dump Height (in.): 71-15/16		1071

KEY: = Expand Model Details = Quickship item = Non-Returnable item = Approval Drawing Required = Non-Cancelable Item
= On Hold/Temporarily Unavailable = Approval Drawing = Testing Certificate = 360 Image Warranty
= Works w/ Skid Only = Flatbed Truck Required

If you did not find an expected Model or SKU # in the table, try the Options Section Below

TCD-U-48-AC
Unit:
Size: W x L x H
Weight:
Limited Warranty
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 48
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 48

TCD-U-48-DC
Unit:
Size: W x L x H
Weight:
Limited Warranty
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 48-9/16
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 48-9/16

TCD-U-60-AC
Unit:
Size: W x L x H
Weight:
Limited Warranty
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 59-15/16
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 59-15/16

TCD-U-60-DC
Unit:
Size: W x L x H
Weight:
Limited Warranty
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 59-13/16
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 59-13/16

TCD-U-72-AC
Unit:
Size: W x L x H
Weight:
Limited Warranty
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 71-15/16
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 71-15/16

TCD-U-72-DC
Unit:
Size: W x L x H
Weight:
Limited Warranty
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 71-15/16
Uniform Capacity (lb.): 400
Maximum Dump Height (in.): 71-15/16
For More Details of the Option Click the Red Model Button
HCP-2642 HCP-2642 Optional Hand Control Pedestal
If you did not find an expected Model or SKU # in this table, try the Product Specifications Section Above
Universal Trash Can Dumpers PDF's will open in a new window when clicked.

Manuals


TCD
Owners Manual

Survey Sheets

No Survey Sheets For This Product


Approval Drawings


TCD-U-48-AC

TCD-U-48-DC

TCD-U-60-AC

TCD-U-60-DC

TCD-U-72-AC

TCD-U-72-DC

Testing Certificates


TCD-U-48-AC

TCD-U-48-DC

TCD-U-60-AC

TCD-U-60-DC

TCD-U-72-AC

TCD-U-72-DC

SDS Sheets

Hydraulic Oil SDS Sheet for: TCD-U-48-AC
Midwest Battery - Lead/Acid Battery, Wet, Filled with Acid SDS Sheet for: TCD-U-48-DC
Hydraulic Oil SDS Sheet for: TCD-U-48-DC
Hydraulic Oil SDS Sheet for: TCD-U-60-AC
Midwest Battery - Lead/Acid Battery, Wet, Filled with Acid SDS Sheet for: TCD-U-60-DC
Hydraulic Oil SDS Sheet for: TCD-U-60-DC
Hydraulic Oil SDS Sheet for: TCD-U-72-AC
Midwest Battery - Lead/Acid Battery, Wet, Filled with Acid SDS Sheet for: TCD-U-72-DC
Hydraulic Oil SDS Sheet for: TCD-U-72-DC

Other PDF's

No "Other PDFs" For This Product...


Directory Links Of Available PDF's For All Products

Manuals
Survey Sheets
Drawings
Certificates of Testing
Warranties
SDS Data Sheets







Visit Our Youtube Channel For All Available Videos For All Products
Reference #: CF-5777 Hydraulic Box Dumper Chute
Reference #: CF-5777 Hydraulic Box Dumper Chute
Reference #: CF-5777 Hydraulic Box Dumper Chute
Special Hydraulic Box Dumper Articulating Chute
For more Specialty Designs similar to these... Click Here

Q: What is the cycle time for the TCD-U-48-DC or the TCD-U-60-DC?

A: Speed is approximately 35 seconds to raise and 35 seconds to lower.

Q: How long does it take to charge the battery for the TCD-U-48-DC or the TCD-U-60-DC?

A: It takes approximately 6-8 hours to charge the battery.

Q: How long does the battery last on the TCD-U-48-DC or the TCD-U-60-DC?

A: Under normal conditions, the battery will last approximately 3.5 hours when raised every 5 minutes. The battery will last approximately 7.5 hours when raised every 10 minutes.
